High energy density.
Fast charge and discharge capabilitie.
High operating current.
plastic case，available with insulated leads.
| Operating temperature range | Max.Operating temperature.,Top, max : +105℃ Upper category temperature: + 85℃ Lower category temperature : - 40℃ |
| Capacitance range | 32μF~200μF |
| Rated voltage | 1500V.DC - 5000V.DC |
| energy | 400J~500J |
| Cap.tol | ±5%(J);±10%(K) |
| Withstand strike current | 5~10kA |
| Withstand voltage | 1.1Un （50ms every time，1000 times during the whole life） |
| lnsulation resistance | Rs ×C≥10000s (at 20℃ 5000V.DC) |
| life time expectancy | 10000 pulse @ 55℃， 95%RH Un |
| Failure rate | 100fit |
| Flame retardation | UL94V-0 |
| Reference standard | JB/T8168 |
Longer lifespan
Compared with the common 10,000 times lifespan in the market, the special film structure design makes CRE’s AED capacitors charge and discharge more than 30,000 times.
Better environmental adaptability
Considering the application in uncertain and harsh environments such as outdoor, AED capacitor adopts a special design of humidity and high-temperature resistance, which has higher reliability.
Higher energy density, smaller size
Specially designed for the small size of AEDs (e.g. handheld AEDs), it uses high energy density materials and is 50% smaller in size and weight than conventional designs.
High energy density.
Fast charge and discharge capabilitie.
High operating current.
plastic case，available with insulated leads.
| Operating temperature range | Max.Operating temperature.,Top, max : +105℃ Upper category temperature: + 85℃ Lower category temperature : - 40℃ |
| Capacitance range | 32μF~200μF |
| Rated voltage | 1500V.DC - 5000V.DC |
| energy | 400J~500J |
| Cap.tol | ±5%(J);±10%(K) |
| Withstand strike current | 5~10kA |
| Withstand voltage | 1.1Un （50ms every time，1000 times during the whole life） |
| lnsulation resistance | Rs ×C≥10000s (at 20℃ 5000V.DC) |
| life time expectancy | 10000 pulse @ 55℃， 95%RH Un |
| Failure rate | 100fit |
| Flame retardation | UL94V-0 |
| Reference standard | JB/T8168 |
Longer lifespan
Compared with the common 10,000 times lifespan in the market, the special film structure design makes CRE’s AED capacitors charge and discharge more than 30,000 times.
Better environmental adaptability
Considering the application in uncertain and harsh environments such as outdoor, AED capacitor adopts a special design of humidity and high-temperature resistance, which has higher reliability.
Higher energy density, smaller size
Specially designed for the small size of AEDs (e.g. handheld AEDs), it uses high energy density materials and is 50% smaller in size and weight than conventional designs.
