Metal case, high energy storage density.
Low Esr, the rise of the internal temperature is small.
Self healing performance is excellent.
High pulse current, high dv/dt withstand capability.
| Operating temperature range | Max.Operating temperature.Top,max : + 70℃ Upper category temperature:+55℃ Lower category temperature:- 40℃ |
| Capacitance range | 0.01μF~50000μF |
| Rated voltage | 3000V.DC ~ 100kV.DC |
| Cap.tol | ±5%（J）；±10%（K） |
| Voltage between terminals | 1.1-1.5Un / 10s（20±5℃） |
| Voltage between terminal and case | 2Un, 60s（20±5℃） |
| Dissipation factor | tgδ<0.002 |
| Energy | 100-100,000J |
| Rs×C ≥10,000s ( at20℃ 100V.DC 60s ) | Rs×C ≥10,000s ( at20℃ 100V.DC 60s ) |
| Flame retardation | UL94V -0 |
| Life expectancy | 1x10^3-1x10^9 shots |
MKMJ-S from CRE has open design for aluminum cases, especially suitable for low inductance requirements.
Current, voltage, size, mass and terminations are matched to the customer requirement and application.
Dry epoxy meets the safety performance and environmental protection.
The design of MKMJ-S is not limited to the catalog range.
Metal case, high energy storage density.
Low Esr, the rise of the internal temperature is small.
Self healing performance is excellent.
High pulse current, high dv/dt withstand capability.
| Operating temperature range | Max.Operating temperature.Top,max : + 70℃ Upper category temperature:+55℃ Lower category temperature:- 40℃ |
| Capacitance range | 0.01μF~50000μF |
| Rated voltage | 3000V.DC ~ 100kV.DC |
| Cap.tol | ±5%（J）；±10%（K） |
| Voltage between terminals | 1.1-1.5Un / 10s（20±5℃） |
| Voltage between terminal and case | 2Un, 60s（20±5℃） |
| Dissipation factor | tgδ<0.002 |
| Energy | 100-100,000J |
| Rs×C ≥10,000s ( at20℃ 100V.DC 60s ) | Rs×C ≥10,000s ( at20℃ 100V.DC 60s ) |
| Flame retardation | UL94V -0 |
| Life expectancy | 1x10^3-1x10^9 shots |
MKMJ-S from CRE has open design for aluminum cases, especially suitable for low inductance requirements.
Current, voltage, size, mass and terminations are matched to the customer requirement and application.
Dry epoxy meets the safety performance and environmental protection.
The design of MKMJ-S is not limited to the catalog range.
